Automatic 55kw 380V Gypsum Ceiling Tile Production Line for PVC Laminated Gypsum Board

Hebei Greens Building Material Technology Development Co.,Ltd
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Automatic 55kw 380V Gypsum Ceiling Tile Production Line for PVC Laminated Gypsum Board

Brand Name : Greens

Model Number : LV--1300SFM(01/02/03)

Certification : ISO CE,

Place of Origin : Hebei, China (Mainland)

MOQ : 1 Line

Price : US $20000-200000

Supply Ability : 10 lines per year

Delivery Time : 2 Months

Packaging Details : standard package

Product Name : Building Materials Production Machine PVC Vinyl Faced Gypsum Board Waterproof False Ceiling Tiles Machine

Keyword : 60x60 PVC Laminated Gypsum Ceiling making machine

Power(W) : 55kw

annual capacity : 2-6million sqm

Color : Customised

Application : Film, machinery production

Raw material : pvc film ,gypsum board, pet film

Automatic Grade : Automatic

Usage : laminate gypsum board

Voltage : 380V

Contact Now

Building Materials Production Machine PVC Vinyl Faced Gypsum Board Waterproof False Ceiling Tiles Machine
Product Specifications
Attribute Value
Power 55kw
Annual Capacity 2-8 million sqm
Color Customized
Application Film, machinery production
Plastic Processed PVC
Raw Material PVC film, gypsum board, PET film
Automatic Grade Automatic
Usage Laminate gypsum board
Voltage 380V
Weight Based on models
Product Overview

This advanced gypsum board automatic cutting machine features the latest double-sided coating and laminating technology, enabling simultaneous coating and gluing of both front (PVC) and reverse sides (aluminum foils) without requiring turn-over.

Key Features
  • Capacity: 7000-12000m² per day (based on standard board dimensions)
  • Automation: Simple operation with high degree of automation
  • Material Compatibility: Works with gypsum board, PVC film, aluminum foil, and specialized adhesives
  • Product Dimensions: Multiple standard sizes available (595×595mm to 1200×600mm)
  • Thickness Range: 7.0mm to 9.0mm
Technical Parameters
Model LV-1300SFM01 LV-1300SFM02 LV-1300SFM03
Max. Laminating Width 1300mm
Thickness Range 5-30mm
Max. Laminating Speed 15m/min
Speed Regulation Frequency conversion synchronous speed regulating
Installed Power 8kw 10kw 20kw
System Components
1. Gypsum Ceiling Board Lamination Machine

Specialized equipment for laminating film on gypsum board with 1220mm laminating width. Features include:

  • Standard gypsum board size: 1220×2440mm
  • Specialized adhesives for PVC film and aluminum foil
  • Max sheet speed: 2-15m/min
  • Thickness range: 2-50mm
  • Motor power: 4.5kw
2. Automatic Feeding Machine

Available in two types:

  • Push-type with cylinder operation (700mm max range)
  • Suction-type for alternative applications
  • Features photoelectric control and rubber roller transmission
  • Cost-effective solution with fully automatic operation
3. Automatic Cutting Machine

Precision cutting system for laminated gypsum boards to standard sizes. Features dual cutting system with pulsed sack-duster option.

4. Automatic Sealing Machine

Right-angle type gypsum board sealing equipment with:

  • PLC photoelectric automatic control
  • High-speed operation with tight, firm edging
  • Quick setup and minimal equipment investment
5. Automatic Shrinking Machine

Heat shrinking system for final packaging:

  • Infrared ray heating technology
  • Packaging speed: 20m/min
  • Weight: 500KG
  • Power: 18.75KW
6. Electrostatic Pulse Bag Style Dust Collector

Efficient dust collection system featuring:

  • Large dust exhaust fan and pipe system
  • Complete system includes collector frame, motor, pipes, and pulse controller
  • Effective dust removal for clean operation
